Cisco ASR 1000 Series Software Configuration Guide

interface serial [slot/subslot/port ].[ds3/t1 ]:[channel-group ]
•
If framing is SONET and mode is T3:
interface serial [slot/subslot/port ].[ds3 ]
SDH Mode
If the aug mapping is au-4, the au-4 value is always 1; if the aug mapping is au-3, then the only supported
mode is c-11 (carrying a T1).
•
If SDH-AUG mapping is au-4 and if the tug-3 is mode t3/e3:
interface serial [slot/subslot/port ].[au-4/tug-3/tug-2/e1 ]:[channel-group ]
•
If SDH-AUG mapping is au-3:
interface serial [slot/subslot/port/au-3/tug-2/t1 ]:[channel-group ]
POS on the 1-Port Channelized OC-12/STM-4 SPA
If framing is SONET and n is from 1-12:
interface pos slot/subslot/port:nsts-1
Required Configuration Tasks
This section lists the required configuration steps to configure the 1-Port Channelized OC-3/STM-1 SPA.
Some of the required configuration commands implement default values that might be appropriate for your
network.
This section includes the following topics:
Configuring the Controller for the SONET Mode and the SDH Mode
Controller configuration is required for both SONET and SDH framing modes. To configure the controller
on the 1-Port Channelized OC-3/STM-1 SPA or 1-Port Channelized OC-12/STM-4 SPA, complete the
following step:
PurposeCommand
Selects the controller to configure and enters
controller configuration mode, where:
• slot/subslot/port —Specifies the location of the
interface.
The port number is always zero on the 1-Port
Channelized OC-3/STM-1 SPA and 1-Port
Channelized OC-12/STM-4 SPA.
Note
Router(config)# controller sonet slot/subslot/port
Cisco ASR 1000 Series Aggregation Services Routers SIP and SPA Software Configuration Guide, Cisco IOS XE
Everest 16.5
OL-14127-17 293
Configuring the 1-Port Channelized OC-3/STM-1 SPA and 1-Port Channelized OC-12/STM-4 SPA
Required Configuration Tasks
