Dell PowerConnect 3524 User Manual

IPv6 Addressing 219
ipv6 default-gateway
The ipv6 default-gateway Global Configuration mode command defines an IPv6 default gateway. Use
the no form of this command to remove the default gateway.
Syntax
• ipv6 default-gateway ipv6-address
• no ipv6 default-gateway
• ipv6-address — IPv6 address of the next hop that can be used to reach that network. When the
IPv6 address is a Link Local address (IPv6Z address), the outgoing interface name must be
specified. Refer to the usage guidelines for the interface name syntax.
Default Configuration
No default gateway is defined.
Command Mode
Global Configuration mode.
User Guidelines
• The IPv6Z address format: < ipv6-link-local-address >%< interface-name >
–
interface-name — vlan < integer > | ch < integer > | isatap < integer > | < physical-port-name > | 0
–
integer — < decimal-number > | < integer >< decimal-number >
–
decimal-number — 0 | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9
–
physical-port-name — Designated port number, for example 1/e16.
• Configuring a new default GW without deleting the previous configured information overwrites
the previous configuration.
• A configured default GW has a higher precedence over automatically advertised (via router
advertisement message).
• If the egress interface is not specified, the default interface will be selected. Specifying interface
zone=0 is equal to not defining an egress interface.
Example
The following example defines an IPv6 default gateway.
Console(config)# ipv6 default-gateway fe80::11
book.book Page 219 Thursday, December 18, 2008 7:40 PM

Dell PowerConnect 3524 Specifications

General

Throughput	9.5 Mpps
Number of queues	4
MAC address table	8000 entries
Maximum data transfer rate	0.1 Gbit/s
Supported data transfer rates	10/100 Mbps
10G support	No
Number of VLANs	256
Flow control support	Yes
Networking standards	IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ad
Input frequency	50/60 Hz
Weight (imperial)	11 lbs
Dimensions (WxDxH)	440 x 257 x 43.2 mm
Networking features	Gigabit Ethernet, Fast Ethernet
Authentication method	RADIUS, TACACS+
Connectivity technology	Wired
Dimensions (W x D x H) (imperial)	17.3 x 10.12 x 1.7 \
Switch type	Managed
Switch layer	L2
Data link protocols	Ethernet
Supported network protocols	HTTP, HTTPS/SSL, SSH
Power connector	DC-in jack
Gigabit Ethernet (copper) ports quantity	2
Basic switching RJ-45 Ethernet ports quantity	24
Product color	Black
Power source	AC
Input voltage	100 - 240 V
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	5000 g
