312 RADIUS Commands
Default Configuration
No RADIUS server host is specified.
The port number for authentication requests is 1812.
The usage type is all.
Command Mode
Global Configuration mode.
User Guidelines
To specify multiple hosts, multiple
radius-server host
commands can be used.
If no host-specific timeout, retries, deadtime or key-string values are specified, global values apply to
each RADIUS server host.
The address type of the source parameter must be the same as the
ip-address
parameter.
Example
The following example specifies a RADIUS server host with IP address 192.168.10.1, authentication
request port number 20 and a 20-second timeout period.
radius-server key
The radius-server key Global Configuration mode command sets the authentication and encryption key
for all RADIUS communications between the device and the RADIUS daemon. Use the no form of this
command to return to the default configuration.
Syntax
radius-server key
[
key-string
]
no radius-server key
key-string
— Specifies the authentication and encryption key for all RADIUS communications
between the device and the RADIUS server. This key must match the encryption key used on the
RADIUS daemon. (Range: 0 - 128 characters)
Default Configuration
The key-string is an empty string.
Command Mode
Global Configuration mode.
Console(config)# radius-server host 192.168.10.1 auth-port 20
timeout 20
book.book Page 312 Thursday, December 18, 2008 7:40 PM

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Dell PowerConnect 3524 and is the answer not in the manual?

Dell PowerConnect 3524 Specifications

General IconGeneral
Throughput9.5 Mpps
Number of queues4
MAC address table8000 entries
Maximum data transfer rate0.1 Gbit/s
Supported data transfer rates10/100 Mbps
10G supportNo
Number of VLANs256
Flow control supportYes
Networking standardsIEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ad
Input frequency50/60 Hz
Weight (imperial)11 lbs
Dimensions (WxDxH)440 x 257 x 43.2 mm
Networking featuresGigabit Ethernet, Fast Ethernet
Authentication methodRADIUS, TACACS+
Connectivity technologyWired
Dimensions (W x D x H) (imperial)17.3 x 10.12 x 1.7 \
Switch typeManaged
Switch layerL2
Data link protocolsEthernet
Supported network protocolsHTTP, HTTPS/SSL, SSH
Power connectorDC-in jack
Gigabit Ethernet (copper) ports quantity2
Basic switching RJ-45 Ethernet ports quantity24
Product colorBlack
Power sourceAC
Input voltage100 - 240 V
Storage temperature (T-T)-20 - 70 °C
Operating temperature (T-T)0 - 45 °C
Storage relative humidity (H-H)10 - 95 %
Operating relative humidity (H-H)10 - 90 %
Weight and Dimensions IconWeight and Dimensions
Weight5000 g
