Dell PowerConnect 3524 User Manual

394 SSH Commands
Default Configuration
Public Key authentication for incoming SSH sessions is disabled.
Command Mode
Global Configuration mode.
User Guidelines
AAA authentication is independent
Example
The following example enables public key authentication for incoming SSH sessions.
crypto key pubkey-chain ssh
The crypto key pubkey-chain ssh Global Configuration mode command enters the SSH Public Key-
chain Configuration mode. The mode is used to manually specify other device public keys such as SSH
client public keys.
Syntax
• crypto key pubkey-chain ssh
Default Configuration
No keys are specified.
Command Mode
Global Configuration mode.
User Guidelines
There are no user guidelines for this command.
Console(config)# ip ssh pubkey-auth
book.book Page 394 Thursday, December 18, 2008 7:40 PM

Dell PowerConnect 3524 Specifications

General

Throughput	9.5 Mpps
Number of queues	4
MAC address table	8000 entries
Maximum data transfer rate	0.1 Gbit/s
Supported data transfer rates	10/100 Mbps
10G support	No
Number of VLANs	256
Flow control support	Yes
Networking standards	IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ad
Input frequency	50/60 Hz
Weight (imperial)	11 lbs
Dimensions (WxDxH)	440 x 257 x 43.2 mm
Networking features	Gigabit Ethernet, Fast Ethernet
Authentication method	RADIUS, TACACS+
Connectivity technology	Wired
Dimensions (W x D x H) (imperial)	17.3 x 10.12 x 1.7 \
Switch type	Managed
Switch layer	L2
Data link protocols	Ethernet
Supported network protocols	HTTP, HTTPS/SSL, SSH
Power connector	DC-in jack
Gigabit Ethernet (copper) ports quantity	2
Basic switching RJ-45 Ethernet ports quantity	24
Product color	Black
Power source	AC
Input voltage	100 - 240 V
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	5000 g
