Dell PowerConnect 3524 User Manual

220 IPv6 Addressing
ipv6 mld join-group
The ipv6 mld join-group interface configuration command configures Multicast Listener Discovery
(MLD) reporting for a specified group. To cancel reporting and leave the group, use the no form of this
command.
Syntax
• ipv6 mld join-group group-address
• no ipv6 mld join-group group-address
• group-address — The multicast group IPv6 address.
Default Configuration
This command has no default setting.
Command Mode
Interface configuration (Ethernet, VLAN, Port-channel).
User Guidelines
•The ipv6 mld join-group command configures MLD reporting for a specified group. The packets that
are addressed to a specified group address will be passed up to the client process in the device.
Example
The following example configures MLD reporting for specific groups.
ipv6 mld version
The ipv6 mld version interface configuration command changes the Multicast Listener Discovery
Protocol (MLD) version. To change to the default version, use the no form of this command.
Syntax
• ipv6 mld version { 1 | 2 }
• no ipv6 mld version
– 1 — Specifies MLD version 1.
– 2 — Specifies MLD version 2.
Default Configuration
MLD version 2.
Console(config-if)# ipv6 mld join-group ff02::10
book.book Page 220 Thursday, December 18, 2008 7:40 PM

Dell PowerConnect 3524 Specifications

General

Throughput	9.5 Mpps
Number of queues	4
MAC address table	8000 entries
Maximum data transfer rate	0.1 Gbit/s
Supported data transfer rates	10/100 Mbps
10G support	No
Number of VLANs	256
Flow control support	Yes
Networking standards	IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ad
Input frequency	50/60 Hz
Weight (imperial)	11 lbs
Dimensions (WxDxH)	440 x 257 x 43.2 mm
Networking features	Gigabit Ethernet, Fast Ethernet
Authentication method	RADIUS, TACACS+
Connectivity technology	Wired
Dimensions (W x D x H) (imperial)	17.3 x 10.12 x 1.7 \
Switch type	Managed
Switch layer	L2
Data link protocols	Ethernet
Supported network protocols	HTTP, HTTPS/SSL, SSH
Power connector	DC-in jack
Gigabit Ethernet (copper) ports quantity	2
Basic switching RJ-45 Ethernet ports quantity	24
Product color	Black
Power source	AC
Input voltage	100 - 240 V
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	5000 g
