Dell PowerConnect 3524 User Manual

302 QoS Commands
Default Configuration
The default configuration is disabled.
Command Mode
Interface Configuration (Ethernet) mode.
User Guidelines
The command can be enabled on a specific port only if port storm-control broadcast enable interface
configuration command is not enabled on that port.
Example
The following example limits the rate of the incoming traffic on Ethernet port 1/e15 to 1000kpbs.
wrr-queue cos-map
The wrr-queue cos-map Global Configuration mode command maps Class of Service (CoS) values to a
specific egress queue. return to the default configuration, use the no form of this command.
Syntax
• wrr-queue cos-map queue-id cos0...cos7
• no wrr-queue cos-map [ queue-id ]
• queue-id — Specifies the queue number to which the CoS values are mapped.
•
cos1...cos7 — Specifies CoS values to be mapped to a specific queue. (Range: 0 - 4)
Default Configuration
The map default values for 4 queues:
• Cos0 is mapped to queue 2
• Cos1 is mapped to queue 1
• Cos2 is mapped to queue 1
• Cos3 is mapped to queue 2
• Cos4 is mapped to queue 3
• Cos5 is mapped to queue 3
• Cos6 is mapped to queue 4
• Cos7 is mapped to queue 4
console(config)# interface ethernet 1/e15
console(config-if) rate-limit 1000
book.book Page 302 Thursday, December 18, 2008 7:40 PM

Dell PowerConnect 3524 Specifications

General

Throughput	9.5 Mpps
Number of queues	4
MAC address table	8000 entries
Maximum data transfer rate	0.1 Gbit/s
Supported data transfer rates	10/100 Mbps
10G support	No
Number of VLANs	256
Flow control support	Yes
Networking standards	IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ad
Input frequency	50/60 Hz
Weight (imperial)	11 lbs
Dimensions (WxDxH)	440 x 257 x 43.2 mm
Networking features	Gigabit Ethernet, Fast Ethernet
Authentication method	RADIUS, TACACS+
Connectivity technology	Wired
Dimensions (W x D x H) (imperial)	17.3 x 10.12 x 1.7 \
Switch type	Managed
Switch layer	L2
Data link protocols	Ethernet
Supported network protocols	HTTP, HTTPS/SSL, SSH
Power connector	DC-in jack
Gigabit Ethernet (copper) ports quantity	2
Basic switching RJ-45 Ethernet ports quantity	24
Product color	Black
Power source	AC
Input voltage	100 - 240 V
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	5000 g
