Dell PowerConnect 3524 User Manual

Contents 3
Contents
Notes and Cautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
1 Using the CLI. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
CLI Command Modes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Introduction
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
User EXEC Mode
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Privileged EXEC Mode
. . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Global Configuration Mode
. . . . . . . . . . . . . . . . . . . . . . . . . 27
Interface Configuration Mode and Specific Configuration Modes
. . . . 28
Starting the CLI
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Editing Features
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Setup Wizard
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Terminal Command Buffer
. . . . . . . . . . . . . . . . . . . . . . . . . 31
Negating the Effect of Commands
. . . . . . . . . . . . . . . . . . . . . 31
Command Completion
. . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Keyboard Shortcuts
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
CLI Command Conventions
. . . . . . . . . . . . . . . . . . . . . . . . . 32
2 Command Groups . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Command Groups
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
AAA Commands
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
ACL Commands
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Address Table Commands
. . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Clock Commands Commands
. . . . . . . . . . . . . . . . . . . . . . . . . . 37
Configuration and Image Files Commands
. . . . . . . . . . . . . . . . . . . 38
DHCP Snooping Commands
. . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Ethernet Configuration Commands
. . . . . . . . . . . . . . . . . . . . . . . 40
book.book Page 3 Thursday, December 18, 2008 7:40 PM

Dell PowerConnect 3524 Specifications

General

Throughput	9.5 Mpps
Number of queues	4
MAC address table	8000 entries
Maximum data transfer rate	0.1 Gbit/s
Supported data transfer rates	10/100 Mbps
10G support	No
Number of VLANs	256
Flow control support	Yes
Networking standards	IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ad
Input frequency	50/60 Hz
Weight (imperial)	11 lbs
Dimensions (WxDxH)	440 x 257 x 43.2 mm
Networking features	Gigabit Ethernet, Fast Ethernet
Authentication method	RADIUS, TACACS+
Connectivity technology	Wired
Dimensions (W x D x H) (imperial)	17.3 x 10.12 x 1.7 \
Switch type	Managed
Switch layer	L2
Data link protocols	Ethernet
Supported network protocols	HTTP, HTTPS/SSL, SSH
Power connector	DC-in jack
Gigabit Ethernet (copper) ports quantity	2
Basic switching RJ-45 Ethernet ports quantity	24
Product color	Black
Power source	AC
Input voltage	100 - 240 V
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	5000 g
