Dell PowerConnect 3524 User Manual

370 Spanning-Tree Commands
Syntax
spanning-tree mst configuration
Default Configuration
This command has no default configuration.
Command Mode
Global Configuration mode.
User Guidelines
All devices in an MST region must have the same VLAN mapping, configuration revision number and
name.
Example
The following example configures an MST region.
instance (mst)
The instance MST Configuration mode command maps VLANS to an MST instance.
Syntax
• instance instance-id {add | remove} vlan vlan-range
• instance-ID — ID of the MST instance. (Range: 1 - 15)
•
vlan-range — VLANs to be added to or removed from the specified MST instance. To specify a
range of VLANs, use a hyphen. To specify a series of VLANs, use a comma. (Range: 1 - 4094)
Default Configuration
VLANs are mapped to the common and internal Spanning Tree (CIST) instance (instance 0).
Command Mode
MST Configuration mode.
Console(config)# spanning-tree mst configuration
Console(config-mst) # instance 1 add vlan 10-20
Console(config-mst) # name region1
Console(config-mst) # revision 1
book.book Page 370 Thursday, December 18, 2008 7:40 PM

Dell PowerConnect 3524 Specifications

General

Throughput	9.5 Mpps
Number of queues	4
MAC address table	8000 entries
Maximum data transfer rate	0.1 Gbit/s
Supported data transfer rates	10/100 Mbps
10G support	No
Number of VLANs	256
Flow control support	Yes
Networking standards	IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ad
Input frequency	50/60 Hz
Weight (imperial)	11 lbs
Dimensions (WxDxH)	440 x 257 x 43.2 mm
Networking features	Gigabit Ethernet, Fast Ethernet
Authentication method	RADIUS, TACACS+
Connectivity technology	Wired
Dimensions (W x D x H) (imperial)	17.3 x 10.12 x 1.7 \
Switch type	Managed
Switch layer	L2
Data link protocols	Ethernet
Supported network protocols	HTTP, HTTPS/SSL, SSH
Power connector	DC-in jack
Gigabit Ethernet (copper) ports quantity	2
Basic switching RJ-45 Ethernet ports quantity	24
Product color	Black
Power source	AC
Input voltage	100 - 240 V
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	5000 g
