Dell PowerConnect 3524 User Manual

Management ACL 247
permit (Management)
The permit Management Access-List Configuration mode command defines a permit rule.
Syntax
• permit [ ethernet interface-number | vlan vlan-id | port-channel port-channel-number ] [ service service ]
•
permit ip-source { ipv4-address | ipv6-address/prefix-length } [ mask mask | prefix-length ] [ ethernet
interface-number | vlan vlan-id | port-channel number ] [ service service ]
•
ethernet interface-number — A valid Ethernet port number.
•
vlan vlan-id — A valid VLAN number.
•
port-channel port-channel-number — A valid port channel index.
•
ipv4-address — Source IPv4 address.
•
ipv6-address/prefix-length — Source IPv6 address and prefix length. The prefix length is optional.
•
mask mask — A valid network mask of the source IP address.
•
mask prefix-length — Number of bits that comprise the source IP address prefix. The prefix length
must be preceded by a forward slash (/). (Range: 0 - 32)
•
service service — Service type. Possible values: telnet , ssh , http, https and snmp .
Default Configuration
If no permit rule is defined, the default is set to deny.
Command Mode
Management Access-list Configuration mode.
User Guidelines
• Rules with Ethernet, VLAN and port-channel parameters are valid only if an IP address is defined on
the appropriate interface.
• The system supports up to 128 management access rules.
Example
The following example permits all ports in the mlist access list.
Console(config)# management access-list mlist
Console(config-macl)# permit
book.book Page 247 Thursday, December 18, 2008 7:40 PM

Dell PowerConnect 3524 Specifications

General

Throughput	9.5 Mpps
Number of queues	4
MAC address table	8000 entries
Maximum data transfer rate	0.1 Gbit/s
Supported data transfer rates	10/100 Mbps
10G support	No
Number of VLANs	256
Flow control support	Yes
Networking standards	IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ad
Input frequency	50/60 Hz
Weight (imperial)	11 lbs
Dimensions (WxDxH)	440 x 257 x 43.2 mm
Networking features	Gigabit Ethernet, Fast Ethernet
Authentication method	RADIUS, TACACS+
Connectivity technology	Wired
Dimensions (W x D x H) (imperial)	17.3 x 10.12 x 1.7 \
Switch type	Managed
Switch layer	L2
Data link protocols	Ethernet
Supported network protocols	HTTP, HTTPS/SSL, SSH
Power connector	DC-in jack
Gigabit Ethernet (copper) ports quantity	2
Basic switching RJ-45 Ethernet ports quantity	24
Product color	Black
Power source	AC
Input voltage	100 - 240 V
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	5000 g
