Dell PowerConnect 3524 User Manual

252 LLDP Commands
Syntax
• lldp enable [rx | tx | both]
•
no lldp enable
• rx — Receive only LLDP packets.
•
tx — Transmit only LLDP packets.
•
both — Receive and transmit LLDP packets (default)
Default Configuration
Enabled in both modes.
Command Modes
Interface Configuration (Ethernet)mode.
User Guidelines
• LLDP manages LAG ports individually. LLDP sends separate advertisements on each port in a LAG.
LLDP data received through LAG ports is stored individually per port.
• LLDP operation on a port is not dependent on STP state of a port. I.e. LLDP frames are sent and
received on blocked ports. If a port is controlled by 802.1X, LLDP operates only if the port is
authorized.
Examples
The following example enables Link Layer Discovery Protocol (LLDP) on an interface.
ll dp timer
The lldp timer command Global Configuration mode command specifies how often the software sends
Link Layer Discovery Protocol (LLDP) updates. Use the no form of this command to revert to the
default setting.
Syntax
• lldp timer seconds
• no lldp timer
• seconds — Specifies in seconds how often the software sends LLDP update.
(Range: 5 - 32768 seconds) .
Console(config)# interface ethernet 1/e5
Console(config-if)# lldp enable
book.book Page 252 Thursday, December 18, 2008 7:40 PM

Dell PowerConnect 3524 Specifications

General

Throughput	9.5 Mpps
Number of queues	4
MAC address table	8000 entries
Maximum data transfer rate	0.1 Gbit/s
Supported data transfer rates	10/100 Mbps
10G support	No
Number of VLANs	256
Flow control support	Yes
Networking standards	IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ad
Input frequency	50/60 Hz
Weight (imperial)	11 lbs
Dimensions (WxDxH)	440 x 257 x 43.2 mm
Networking features	Gigabit Ethernet, Fast Ethernet
Authentication method	RADIUS, TACACS+
Connectivity technology	Wired
Dimensions (W x D x H) (imperial)	17.3 x 10.12 x 1.7 \
Switch type	Managed
Switch layer	L2
Data link protocols	Ethernet
Supported network protocols	HTTP, HTTPS/SSL, SSH
Power connector	DC-in jack
Gigabit Ethernet (copper) ports quantity	2
Basic switching RJ-45 Ethernet ports quantity	24
Product color	Black
Power source	AC
Input voltage	100 - 240 V
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	5000 g
