LLDP Commands 265
show lldp neighbors
Syntax
• show lldp neighbors [ ethernet interface ]
•
Interface — Ethernet port
Command Modes
Privileged EXEC mode.
User Guidelines
There are no user guidelines for this command.
Example
The following example displays information about neighboring devices discovered using Link Layer
Discovery Protocol (LLDP).
console# show lldp neighbors
v
Port Device ID Port ID Hold
Time
Capabilities System Name
---- ------ ---- ------ ------- --------
e1 0060.704C.73FE 1 117 B ts-7800-2
e1 0060.704C.73FD 1 93 B ts-7800-2
e2 0060.704C.73F C 9 1 B, R ts-7900-1
e3
0060.704C.73FB 1 92 W ts-7900-2
console# show lldp neighbors ethernet g1
Device ID: 0060.704C.73FE
Port ID: 1
Hold Time: 117
Capabilities: B
System Name: ts-7800-2
System description:
Port description:
Management address: 172.16.1.1
book.book Page 265 Thursday, December 18, 2008 7:40 PM

Dell PowerConnect 3524 Specifications

General

Throughput	9.5 Mpps
Number of queues	4
MAC address table	8000 entries
Maximum data transfer rate	0.1 Gbit/s
Supported data transfer rates	10/100 Mbps
10G support	No
Number of VLANs	256
Flow control support	Yes
Networking standards	IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ad
Input frequency	50/60 Hz
Weight (imperial)	11 lbs
Dimensions (WxDxH)	440 x 257 x 43.2 mm
Networking features	Gigabit Ethernet, Fast Ethernet
Authentication method	RADIUS, TACACS+
Connectivity technology	Wired
Dimensions (W x D x H) (imperial)	17.3 x 10.12 x 1.7 \
Switch type	Managed
Switch layer	L2
Data link protocols	Ethernet
Supported network protocols	HTTP, HTTPS/SSL, SSH
Power connector	DC-in jack
Gigabit Ethernet (copper) ports quantity	2
Basic switching RJ-45 Ethernet ports quantity	24
Product color	Black
Power source	AC
Input voltage	100 - 240 V
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	5000 g
