Emerson Mentor MP User Manual

Parameter structure
Keypad and display
Parameter x.00
Parameter
description
protocol
Performance
different
from
European
defaults.
3.4
Differences
between
European
and
USA
defaults
format
Advanced parameter
descriptions
Serial comms
7. When the drive mode is changed all data in the EEPROM is deleted
and then restored with the defaults for the new mode. If the power is
removed during a change of drive mode, an EEF trip is likely to
occur on the next power-up. After a change of drive mode the power
down save parameters are also saved. As these parameters are not
saved if the power is removed unless the drive is supplied with a
normal line power supply, this ensures that the power down save
parameters are always stored correctly for the new drive mode. The
first time parameters are saved after the change of drive mode the
save will take slightly longer than a normal parameter save.
8. When an Solutions Module is changed for a different type in a slot,
or a module is inserted when one was not present previously or a
module is removed the EEPROM is forced to re-initialise itself on the
next parameter saves. On the first parameter save one bank is
cleared and then written and on the next parameter save the other
bank is cleared and rewritten. Each of these parameter saves takes
slightly longer than a normal parameter save.
3.3 Loading defaults
When defaults are loaded the user save parameters are automatically
saved to the drive EEPROM in all modes. Standard defaults are loaded
by setting Eur or USA in Pr x.00 performing a drive reset.
When the drive is a single quadrant drive the following parameters are
3.5 SMARTCARD transfers
Drive parameters, setup macros and internal ladder programs can be
transferred to/from SMARTCARDs. See Pr 11.36 to Pr 11.40 .
3.6 Display non-default values or
destination parameters
If a diS.diFF is selected in Pr x.00 , then only parameters that are
different from the last defaults loaded and Pr x.00 are displayed. If
diS.dESt is selected in Pr x.00 , then only destination parameters are
displayed. This function is provided to aid locating destination clashes if
a dESt trip occurs.
16 Mentor MP Advanced User Guide
www.onxcontrol.com Issue Number: 4
Pr
Description
Default
2.06
S
ramp
enable
Eur:
OFF
(0)
,
USA:
On
(1)
3.51
Tachometer
voltage
rating
(Fb02, 0.72)
Eur: 60.00, USA: 50.00
5.09
,
21.09
Armature
rated
voltage
(SE06, 0.27)
480
V
drive
Eur:
440,
USA:500
5.28
Field
weakening
compensation disable
Eur: OFF (0), USA On (1)
5.59
,
21.08
Back emf set point
480
V
drive
Eur:
440,
USA:500
5.65
Economy
timeout
Eur:
OFF
(0),
USA:
On
(1)
5.70 ,
21.24
Rated field current
(SE10, 0.31)
Size
1:
Eur:
2.00,
USA:
8.00
Size 2A & B Eur: 3.00, USA:
20.00 Size 2C & D Eur: 5.00,
USA 20.00
5.73
,
21.23
Rated
field
voltage
(SE11, 0.32)
Eur: 360, USA: 300
5.75
Field
voltage
mode
Eur:
OFF
(0),
USA:
On
(1)
7.15
Analog
input
3
mode
(in01, 0.81)
Eur: th (8), USA: VOLt (6)
Pr
Description
Default
1.10
Bipolar
reference
enable
0
5.22
Quadrant
2
enable
0
5.24
Quadrant
4
enable
0
