structure
Keypad and
format
Advanced
parameter
descriptions
Serial comms
5.16
Menus
15,
16
and
17:
Solutions
Module
slots
Pr
x.00
and Pr
x.01
are always present in menus 15, 16 and 17. Pr
x.01
indicates which type of module is present (0 = no module installed). When a
module is installed the drive provides the relevant menu (menu 15 for slot 1, 16 for slot 2 and 17 for slot 3) depending on the Solutions Module
Most modules include a processor and parameters are updated by the processor in the Solutions Module. However, dumb modules do not contain a
processor and all parameters are updated by the drive processor.
Dumb Solutions Module parameters are read/written by the drive background task or at the combined update time for time critical parameters. The
combined update time depends on the number and type of dumb Solutions Modules installed to the drive. For each Solutions Module the update rate
of these parameters is specified as 4 ms, 8 ms, etc. The combined update time is the total of the update times for all dumb Solutions Modules
installed.
For example, if a module with 4 ms update time and a module with 8 ms are installed to the drive, then the combined update time for the time critical
parameters of each module is 12 ms.
In the parameter tables the update time added by the type of module is given, for example 4 ms for the SM-Encoder Plus or 8 ms for the SM-I/O Plus.
When parameters are saved by the user in the drive EEPROM the option code of the currently installed module is saved in EEPROM. If the drive is
subsequently powered-up with a different module installed, or no module installed where a module was previously installed, the drive gives a Slot.dF
trip. The menu for the relevant slot appears for the new module category with the default parameter values for the new category. The new parameters
values are not stored in EEPROM until the user performs a parameter save.
186
Mentor MP Advanced User Guide
