one parameter is active, the highest priority takes precedence.
Pr
1.41
= 1 forces Pr
1.49
= 2 (see table in Pr
1.14
on page 27 and Pr
1.15
on page 28)
Pr
1.42
= 1 forces Pr
1.49
= 3 (always selects preset references)
Pr
1.43
= 1 forces Pr
1.49
= 4 (always selects keypad control mode)
Pr
1.44
= 1 forces Pr
1.49
= 5 (always selects precision reference)
Pr
1.52
= 1 forces Pr
1.49
= 6 (Keypad reference only)
Pr
1.45
to Pr
1.47
control Pr
1.50.
Pr
1.45
controls Pr
1.50
bit 0*
Pr
1.46
controls Pr
1.50
bit 1*
Pr
1.47
controls Pr
1.50
bit 2*
*See the description with Pr
1.14
{
SE05,
0.26
} and Pr
1.15
on page 28 for more information.
sequence of reference selection by a programmable input terminal or function. When this bit is zero the preset selection will follow the timer even
when the drive is disabled.
32
Mentor MP Advanced User Guide
www.onxcontrol.com
Issue Number: 4
