WARNING
WARNING
The brake control functions are provided to allow well co-ordinated operation of an external brake with the drive. While both hardware and
software are designed to high standards of quality and robustness, they are not intended for use as safety functions, i.e. where a fault or
failure would result in a risk of injury. In any application where the incorrect operation of the brake release mechanism could result in injury,
independent protection devices of proven integrity must also be incorporated.
The control terminal relay can be selected as an output to release a brake. If a drive is set up in this manner and a drive replacement takes
place, prior to programming the drive on initial power up, the brake may be released.When drive terminals are programmed to non default
settings the result of incorrect or delayed programming must be considered. The use of a SMARTCARD in boot mode or an SM-
Applications module can ensure drive parameters are immediately programmed to avoid this situation.
Figure
5-31
Menu
12
Brake
control
function
External field
12.51
External brake
released indicator
12.54
Post brake
release delay
12.47
Brake release
action
12.49
Position control
Flux feedback
1
0
mode
13.10
=1
5.54
+
-
0
1
2
threshold
Field Active
12.50
LATCH
Jog override
(Menu 6)
Positive torque only
12.53
12.55
Brake release source
Current magnitude
0
1
0
4.01
+
Brake Release
1
12.43
-
Torque
present
LATCH
12.40
Drive Active
Torque proving
threshold
10.02
6.08
Hold zero
speed
Reference On
1.11
Speed feedback
12.48
12.41
Brake apply delay
Brake controller
enable
3.02
+
-
input
output
Brake apply
speed
12.45
12.46
Brake apply speed
delay
reset
LAT
Key
1.
If the reset input is 1 the output is 0
2.
If the reset input is 0 the output latches at 1 if the input is 1
Input
terminals
0.XX
Read-write (RW)
parameter
Output
Read-only
(RO)
parameter
Mentor MP Advanced User Guide
167
Issue Number: 4
