The radar bearing is adjustable in one degree increments on the Navigation Map Page by pushing the Joystick
left or right when the overlay is enabled. A left or right arrow next to the bearing readout indicates the direction
of the selected bearing. The cyan radar bearing line is only viewable on the Weather Radar Page. While the
bearing line is not shown on the Navigation Map Page, adjusting the bearing on the Navigation Map Page while
Sector Scan is enabled centers the radar scan on the selected bearing, and the radar scan boundaries adjust
accordingly on the Navigation Map Page.
Radar antenna tilt angle is adjustable in 0.25 degree increments on the Navigation Map Page. Push the
Joystick up to adjust the antenna tilt angle downward. Push the Joystick down to adjust the antenna tilt angle
upward. An up or down arrow next to the antenna tilt angle setting indicates the direction of the antenna tilt
angle.
The weather radar overlay uses the same colors as those shown on the Weather Radar Page to indicate the
intensity of radar returns. However, the display of gray WATCH radar attenuation and red weather alert
target bands is exclusive to the Weather Radar Page. Because relative terrain information uses similar colors,
enabling the airborne weather radar overlay on the Navigation Map Page disables the display of relative terrain
information for this page.
SYSTEM STATUS
The radar mode is annunciated in the upper left corner of the Weather Radar Page. Additional information
may be displayed in the center of the Weather Radar Page as a banner annunciation.
Radar Mode
Radar Mode Annunciation Box†
Center Banner Annunciation
Standby STANDBY STANDBY
Standby (During Warm-Up),
applicable to GWX 68 only
STANDBY
WARM-UP
XX
(XX indicates number of seconds
remaining in warm-up)
Weather WEATHER None
Ground Mapping GROUND MAPPING None
Off OFF OFF
Radar Failed* FAIL RADAR FAIL
† Annunciations in this column appear in white text in the Weather Radar Mode box on the Navigation Map
Page.
* See Table 6-19 for additional failure annunciations
Table 6-17 Radar Modes on the Weather Radar Page
