Garmin G1000 Pilot’s Guide for the Diamond DA42NG
190-00-00962-04 Rev. A
454
HAZARD AVOIDANCE
SYSTEM
OVERVIEW
FLIGHT
INSTRUMENTS
EIS
AUDIO PANEL
& CNS
FLIGHT
MANAGEMENT
HAZARD
AVOIDANCE
AFCS
ADDITIONAL
FEATURES
APPENDICESINDEX
SYSTEM STATUS
The traffic mode is annunciated in the upper left corner of the Traffic Map Page.
Mode
Traffic Mode Annunciation
(Traffic Map Page)
Traffic Map Page Center
Banner Annunciation
Traffic Display Status Icon
(Other Maps)
ADS-B System Test
Initiated
ADS-B: TEST TEST MODE
ADS-B Operating in
Airborne Mode
ADS-B: AIRB ADS-B: AIRB
ADS-B Operating in
Surface Mode
ADS-B: SURF ADS-B: SURF
ABD-B Traffic Off ADS-B: OFF ADS-B TRFC OFF
ADS-B Traffic Not
Available
ADS-B: N/A ADS-B TRFC N/A
ADS-B Failed* ADS-B: FAIL ADS-B TRFC FAIL
* See Table 6-41 for additional failure annunciations
Table 6-40 Traffic Modes
If the traffic unit fails, an annunciation as to the cause of the failure is shown in the center of the Traffic Map
Page. During a failure condition, the Operating Mode cannot be selected.
Traffic Map Page Center
Annunciation
Description
NO DATA Data is not being received from the traffic unit
DATA FAILED
Data is being received from the traffic unit, but the
unit is self-reporting a failure
ADS-B TRFC FAIL Incorrect data format received from the traffic unit
Table 6-41 Traffic Failure Annunciations
The annunciations to indicate the status of traffic information appear in a banner at the lower left corner of
maps on which traffic can be displayed.
