APPENDIX A
WEATHER RADAR ALERTS AND ANNUNCIATIONS
Radar Mode
Radar Mode Annunciation Box†
Center Banner Annunciation
Standby STANDBY STANDBY
Standby (During Warm-Up),
applicable to GWX 68 only
STANDBY
WARM-UP
XX
(XX indicates number of seconds
remaining in warm-up)
Weather WEATHER None
Ground Mapping GROUND MAPPING None
Off OFF OFF
Radar Failed* FAIL RADAR FAIL
† Annunciations in this column appear in white text in the Weather Radar Mode box on the Navigation Map
Page.
Radar Modes on the Weather Radar Page
Radar Feature Status Description
ACT ON Altitude compensated tilt feature is enabled (GWX 70 only)
ACT OFF Altitude compensated tilt feature is disabled (GWX 70 only)
STAB ON Antenna stabilization is selected on.
STAB OFF Antenna stabilization is selected off.
STAB INOP
The radar is not receiving pitch and roll information. The
antenna stabilization feature is inoperative.
Radar Feature Annunciations on the Weather Radar Page
Weather Radar
Page Center Banner
Annunciation
Description
BAD CONFIG The radar configuration is invalid. The radar should be serviced.
RDR FAULT The radar unit is reporting a fault. The radar should be serviced.
RADAR FAIL
The system is not receiving valid data from the radar unit. The system
should be serviced.
Abnormal Radar Status Annunciations on the Weather Radar Page
