SYSTEM STATUS
NOTE: Refer to the TAS600 documentation for information on the operating mode.
The traffic mode is annunciated in the upper left corner of the Traffic Map Page.
Mode
Traffic Mode Annunciation
(Traffic Map Page)
Traffic Display Enabled Icon
(Other Maps)
TAS Operating OPERATING
TAS Failed* FAIL
* See Table 6-34 for additional failure annunciations
Table 6-33 TAS Modes
If the unit fails, an annunciation as to the cause of the failure is shown in the center of the Traffic Map Page.
Traffic Map Page Annunciation Description
NO DATA Data is not being received from the TAS unit
DATA FAILED
Data is being received from the TAS unit, but the
unit is self-reporting a failure
FAILED Incorrect data format received from the TAS unit
Table 6-34 TAS Failure Annunciations
The annunciations to indicate the status of traffic information appear in a banner at the lower left corner of
maps on which traffic can be displayed.
Traffic Status Banner
Annunciation
Description
TA OFF SCALE
A Traffic Advisory is outside the selected display
range*
Annunciation is removed when traffic comes within
the selected display range
TA X.X ± XX ↕
System cannot determine bearing of Traffic
Advisory**
Annunciation indicates distance in nm, altitude
separation in hundreds of feet, and altitude trend
arrow (climbing/descending)
TRFC FAIL
TAS unit has failed (unit is self-reporting a failure or
sending incorrectly formatted data)
NO TRFC DATA Data is not being received from the TAS unit
*Shown as symbol on Traffic Map Page
**Shown in center of Traffic Map Page
Table 6-35 TAS Traffic Status Annunciations
