APPENDIX A
ADS-B ALERTS AND ANNUNCIATIONS
Mode
Traffic Mode Annunciation
(Traffic Map Page)
Traffic Map Page Center
Banner Annunciation
Traffic Display Status Icon
(Other Maps)
ADS-B System Test
Initiated
ADS-B: TEST TEST MODE
ADS-B Operating in
Airborne Mode
ADS-B: AIRB ADS-B: AIRB
ADS-B Operating in
Surface Mode
ADS-B: SURF ADS-B: SURF
ABD-B Traffic Off ADS-B: OFF ADS-B TRFC OFF
ADS-B Traffic Not
Available
ADS-B: N/A ADS-B TRFC N/A
ADS-B Failed* ADS-B: FAIL ADS-B TRFC FAIL
Traffic Modes
Traffic Map Page Center
Annunciation
Description
NO DATA Data is not being received from the traffic unit
DATA FAILED
Data is being received from the traffic unit, but the
unit is self-reporting a failure
ADS-B TRFC FAIL Incorrect data format received from the traffic unit
Traffic Failure Annunciations
Traffic Status Banner
Annunciation
Description
TA OFF SCALE
A Traffic Advisory is outside the selected display range*.
Annunciation is removed when traffic comes within the
selected display range.
TA X.X ± XX ↕
System cannot determine bearing of Traffic Advisory**.
Annunciation indicates distance in nm, altitude separation
in hundreds of feet, and altitude trend arrow (climbing/
descending).
TRFC FAIL
Traffic unit has failed (unit is self-reporting a failure or
sending incorrectly formatted data)
NO TRFC DATA Data is not being received from the traffic unit
*Shown as symbol on Traffic Map Page
**Shown in center of Traffic Map Page
Traffic Status Annunciations
