APPENDIX A
GDL 69A/GDL 69A SXM DATA LINK RECEIVER MESSAGES
Message Message Location Description
CHECK ANTENNA XM Radio Page - active channel field Data Link Receiver antenna error; service required
UPDATING XM Radio Page - active channel field Data Link Receiver updating encryption code
NO SIGNAL
XM Radio Page - active channel field
Weather Datalink Page - center of page
Loss of signal; signal strength too low for receiver
LOADING XM Radio Page - active channel field Acquiring channel audio or information
OFF AIR XM Radio Page - active channel field Channel not in service
--- XM Radio Page - active channel field Missing channel information
WEATHER DATA LINK FAILURE Weather Datalink Page - center of page
No communication from Data Link Receiver
within last 5 minutes
DETECTING ACTIVATION Weather Datalink Page - center of page SiriusXM subscription is not activated

Garmin G1000 Specifications

General

Display Type	LCD
Primary Flight Display (PFD)	Yes
Multi-Function Display (MFD)	Yes
Terrain Awareness	Yes
Autopilot Integration	Yes
Integrated Flight Deck System	Yes
Weather Radar	Optional
Traffic Advisory System (TAS)	Optional
Terrain Awareness and Warning System (TAWS)	Yes
Resolution	1024 x 768 pixels
Weather Data	Yes
Navigation	Yes
AHRS	Yes
Air Data Computer (ADC)	Yes
Interfaces	ARINC 429, RS-232
Certification	TSO certified
Traffic Information	Optional (requires ADS-B or TCAS)
