Garmin G1000 Pilot's Guide

190-00962-04 Rev. A
Garmin G1000 Pilot’s Guide for the Diamond DA42NG
463
AUTOMATIC FLIGHT CONTROL SYSTEM
SYSTEM
OVERVIEW
FLIGHT
INSTRUMENTS
EIS
AUDIO PANEL
& CNS
FLIGHT
MANAGEMENT
HAZARD
AVOIDANCE
AFCS
ADDITIONAL
FEATURES
APPENDICES INDEX
7.3 VERTICAL MODES
Table 7-2 lists the vertical modes with their corresponding controls and annunciations. The mode reference is
displayed next to the active mode annunciation for Altitude Hold, Vertical Speed, and Flight Level Change modes.
The NOSE UP/NOSE DN Keys can be used to change the vertical mode reference while operating under Pitch
Hold, Vertical Speed, or Flight Level Change Mode. Increments of change and acceptable ranges of values for
each of these references using the NOSE UP/NOSE DN Keys are also listed in the table.
Vertical Mode Description Control Annunciation
Reference
Range
Reference
Change
Increment
Pitch Hold
Holds aircraft pitch attitude; may
be used to climb/descend to the
Selected Altitude
(default) PIT -15° to +20° 0.5°
Selected Altitude Capture Captures the Selected Altitude * ALtS
Altitude Hold Holds current Altitude Reference ALT Key ALT nnnnn ft
Vertical Speed
Holds aircraft vertical speed; may
be used to climb/descend to the
Selected Altitude
VS Key VS nnnn fpm
-3000 to
+1500 fpm
100 fpm
Flight Level Change
Holds aircraft airspeed while
aircraft is climbing/descending to
the Selected Altitude
FLC Key FLC nnn kt 90 to 180 kt 1 kt
Vertical Path Tracking
Captures and tracks descent legs
of an active vertical profile
VNV
Key
VPTH
VNV Target Altitude Capture
Captures the Vertical Navigation
(VNV) Target Altitude
** ALTV
Glidepath***
Captures and tracks the SBAS
glidepath on approach
APR
Key
GP
Glideslope
Captures and tracks the ILS
glideslope on approach
GS
Go Around
Commands a constant pitch
angle and wings level
GA
Button
GA 6°
* ALTS is armed automatically when PIT, VS, FLC, or GA is active, and under VPTH when the Selected Altitude is to be captured
instead of the VNV Target Altitude.
** ALTV is armed automatically under VPTH when the VNV Target Altitude is to be captured instead of the Selected Altitude.
***GP is available in installations with GIA 63W IAUs when SBAS is available.
Table 7-2 Flight Director Vertical Modes
