9.1.2.5 Traffic (Optional)
The Traffic group selection from the Map Setup Page Menu allows you to
customize the display of traffic on the Map page. The Traffic function requires
the installation of the appropriate traffic device. Only one traffic source can be
configured for the GTN and this traffic source will be overlaid on the main map.
Coverage follows the airplane. In the Navigation Map page setup you can select
the maximum range at which traffic symbols are shown. Once outside of the
selected range, traffic will be decluttered. The default values are shown in bold
type.
Traffic Selection Display Result
Range 1 NM, 1.5 NM, 2.5 NM, 4 NM, 5 NM, 7.5 NM, 10 NM,
15 NM, 25 NM
Traffic All Traffic, Alerts & Advisories, Alerts Only
Restore Defaults Returns values to original factory settings
Table 9-5 Map Page Traffic Display Options
9.1.2.6 Weather (Optional)
The Weather group selection from the Map Setup Page Menu allows you to
customize the overlay of the available weather information on the Map page.
Weather is an optional feature that requires an external weather source, which
must be selected to allow the overlay.
Feature Selection
Weather Source SiriusXM, Connext, or FIS-B
Cell Movement Off, On
METAR Off, On
Cloud Tops Off, On
Echo Tops Off, On
Lightning Off, On
Restore Defaults Returns values to original factory settings
Table 9-6 Map Setup SiriusXM Weather Options
NOTE: Map overlay keys may remain available even if the information
necessary for the overlay is not available. For example: the Radar overlay
key is available even if the radar is turned off.
