18.5 Basemap Symbols
Symbol Description
Interstate Highway
State Highway
US Highway
National Highway - 2-digit drawn inside
Small City or Town
Medium City
Large City
Table 18-8 Basemap Symbols
18.6 Map Tool Bar Symbols
Symbol Description
Terrain Proximity Enabled and Available Indicator
Terrain Proximity Enabled and Not Available Indicator
StormScope
Within coverage of a TIS-B ground station when connected to a
GDL 88
Not within coverage of a TIS-B ground station when connected to
a GDL 88
Traffic Enabled and Available Indicator
Traffic Enabled and Not Available Indicator
Table 18-9 Map Tool Bar Symbols
