Select the appropriate button for the cine you prefer.
Note
Not all kinds of cine are available in all visualization modes, see table below.
The following table shows the dependences
3D Rot. Cine
3D Transl. Cine
Slice Cine
Full View
Quad View
Full View
Quad View
Full View
Render
X
X
X
-
-
Sectional
Planes
-
-
-
X
X
TUI
-
-
-
-
-
VOCAL
X
-
-
-
-
VCAD
-
-
-
-
-
Volume Mode
9-58
Voluson® S6/S8 Basic User Manual
5433669-100 Revision 4
275
277
