3. Define the reference line, using the trackball. Accept with left or right trackball.
4.
Measure the all areas. When the measurement is done the next line will be highlighted. If
the last area is measured press the Done button.
5. If necessary correct the measurements.
6. Press Done to finish the measurement.
11.2.4.21 Obstetric - Subcategory: Fetal Echo
This subcategory allows you to measure the fetal heart.
Application “Obstetric”, (Factory - Sub Category: Fetal Echo) allows measurements/
calculations in 2D/3D mode using various measure items. For details about settings, review:
Measure Setup -
Measure & Calc
(chapter
'The Measure Setup Pages'
on page 11-109
)
The methods for obtaining measurements (e.g., Aortic Arch View, etc.) in the Obstetric
Calculations menu are similar to the generic measurement functions in 2D.
11.2.4.22 Items of Obstetric Calculations - Subcategory: Fetal Echo
The items of obstetric calculations in each mode are as follows:
2D/3D Mode: 4 Chamber View, Thorax, Outflow Tract, Aortic Arch,
Venous, LVOT, RVOT
M Mode: 4 Chamber View, Outflow Tract
, FHR
Doppler Mode: Tricuspid Valve, Mitral Valve, Main Pulmonary Artery,
Aorta, Ductus Art., Umbilical Vein, Ductus Venosus,
FHR, LVOT, RVOT, Pulmonary Veins, Pulmonary
Valve, Aortic Valve
Description of Abbreviations review:
Chapter 17
11.2.4.23 Obstetric - Worksheet
Press the [Worksheet] key on the control panel to view the report that contains detailed results
of obstetric calculations.
Measurements and Patient Worksheets (Reports)
Voluson® S6/S8 Basic User Manual
5433669-100 Revision 4 11-53
To Next Page
