Picture Key Action
Repro Reproduce a scan.
'Repro'
on page 12-36
Data Transfer Switches to Data Transfer Menu, see 'Data
Transfer Menu'
on page 12-25
End Exam Closes the active exam. This button is only
available, if the exam displayed in "Exam
Review" Mode, is the currently active
exam.
Exit Close the "Exam Review" dialog and
return to the running exam. The exam can
also be close by pressing the “Exit” or the
“Freeze” keys on the User Interface.
Layout Use the drop-down menu to select how
many images of the selected exam you
wish to view, see 'Formats'
on page 12-
38
Double-Click on
Display the image, that was double-
clicked, as Full Screen.
Arrow Keys Use the arrow keys (2 and 3) to navigate
through the exam row by row, and turn
pages (when the end of a page is reached)
or use the upper (1) and the lower (4)
arrow key to go to the first respectively the
last image.
Numbering
The image numbering allows you to
navigate through exams easily. The
numbers left of the stroke show the current
images and right of a stroke the overall
number of images.
Reload Reload the according data set into the
system. This button only works with 3D/4D
data and raw data, see
'Reload'
on page
12-35
Image Properties Opens the "Image Properties" dialog of the
according image, see
'Image Area'
on
page 12-24
Archive
12-32
Voluson® S6/S8 Basic User Manual
5433669-100 Revision 4
