P/N 960-100189RA_Rev. A {EDP #148850} © 2009, Japan CashMachine Co., Limited
VEGA™ Series
BankNote Validator
Section 1
This section provides a general overview of the
VEGA BankNote Validatior pictured in Figure 1-1.
This first section is designed
to help you navigate
through the manual with ease and provides the
following information:
•
Model/Type Number Specifications
•
Precautions
•
Primary Features
•
Component Names
•
System Configuration
•
Specifications
•
VEGA Unit Dimensions.
In order to make operation of this device easier and
make
navigation within this manual simpler, the
following illustrations were used within the text:
•
Safety Instructions, which need to be
observed in order to protect both the operators
and equipment, have been written in bold text
and have been given the pictograph:
•
Special Notes, which effect the use of the
Banknote Validator, have been written in italic
text and have been given the pictograph:
•
Steps, requiring the operator to perform
specific actions are given sequential numbers
(1., 2., 3., etc.).
Figure 1-1 VEGA Unit Assembly
