JCM VEGA Series User Manual

P/N 960-100189RA_Rev. A {EDP #148850} © 2009, Japan CashMachine Co., Limited
1-7
General Information VEGA™ Series BankNote Validator Section 1
E LECTRICAL S PECIFICATIONS
S TRUCTURAL S PECIFICATIONS
Table 1-5: VEGA Electrical Specification
Supply Voltage
a
:
a. Hot-swapping is prohibited (e.g., do not plug connectors in or out while the power is ON).
12V DC (±5%) 2.0A REcommended
12V DC (±5%) 5.0A REcommended (VEGA & VEGA-RC Specification)
Current Consumption:
Standby = 0.2A (12V DC)
Operation = 0.7A (Max:0.8A) (12V DC)
Table 1-6: V
EGA Structural Specification
Weight:
Unit: Approximately 2kg (4.409 lbs)
Cash Box: Approximately 0.8kg (1.763 lbs)
Mounting:
a
a. Both vertical and transverse types should be installed at 90 degrees to the Frame.
Horizontal (SH Type)
Vertical Surface Installation (SU/SD Type)
Cash Box Limit Stop:
a) Rear Installation (Front Access) (SHF Type)
b) Front Installation (Rear Access) (SHR Type)
Outer Dimensions:
168mm (6.61 in) High x 221.5mm (8.72 in) Deep x 104mm (4.09 in)
Wide.
b
b. Without a 12mm width Faceplate.
