JCM VEGA Series User Manual

P/N 960-100189RA_Rev. A {EDP #148850} © 2009, Japan CashMachine Co., Limited
7-21
Exploded Views and Parts Lists VEGA™ Series BankNote Validator Section 7
VEGA Option Unit Parts List
Table 7-9 VEGA Option Unit Parts List
Ref N
o
. EDP N
o
. JAC N
o
.
Description Qty. Remark
OP1 149632 200-101165R Face Cover 1
OP2 149633 200-101166R Face Cover Bracket Right 1
OP3 149634 200-101167R Face Cover Bracket Left 1
OP4 149635 149-000010R
M3x4 Flathead, Phillips, F-Lock 3M
Smal
l Screw
4
OP5 080908 149-000011R
3x6 Phillips, Self Tightening, Binding
3M
Screw
2
OP6 149643 200-101168R Key Cover 1
OP7 149644 200-101169R Key Lever 1
OP8 149645 200-101170R Key Bracket 1
OP9 149646 200-101171R Key Tang 1
OP10 149984 200-101172R Key Shaft 1
OP11 149985 149-000012R
M2.6x6 Flathead, Phillips, 3M Small
Screw
1
OP12 117252 149-000013R M2.6x3 Flathead, Phillips, 3M Screw 2
OP13 003595 177-000003R
M2.6x4 Panhead, Phillips, 3M Small
Wa
sher
1
OP14 003668 140-000633R M2.6 Hex Nut 1
OP15 006098 142-000010R Ø2.6 Spring Washer 1
OP16 003707 100-100043 Ø3 E-Ring 1
