JCM VEGA Series User Manual

P/N 960-100189RA_Rev. A {EDP #148850} © 2009, Japan CashMachine Co., Limited
7-10
Exploded Views and Parts Lists VEGA™ Series BankNote Validator Section 7
VEGA Course Path Turning Unit Parts List
Table 7-4 VEGA Course Path Turning Unit Parts List
Ref N
o
. EDP N
o
. JAC N
o
.
Description Qty. Remark
301 144569 900-200320R Course Path Turning Guide 1
302 144570 900-200321R Course Path Turning Guide Cover 1
303 144581 900-200322R
Course Path Turning Guide Cover
La
tch
2
304 144558 200-200793R Latch Coil Spring 1 2
305 110909 900-101014RA Prism C 1
306 144607 900-200304R Pinch Roller 4
307 144610 200-200730R Pinch Roller Shaft 2
308 144556 200-200730R Pinch Roller Coil Spring 4
