JCM VEGA Series User Manual

P/N 960-100189RA_Rev. A {EDP #148850} © 2009, Japan CashMachine Co., Limited
7-19
Exploded Views and Parts Lists VEGA™ Series BankNote Validator Section 7
VEGA SD/SU/SDB/SUB Unit Bezel Type N Parts List
Table 7-8 VEGA SD/SU/SDB/SUB Unit Bezel Type N Parts List
Ref N
o
.
EDP Number
JAC N
o
.
Description Qty. Remark
701 149617 902-100506R Bezel SD/SU Type N 1 Type N2 (76mm)
702 149619 900-101198R
Face Upper SD/SU Guide
Type N2 (76mm)
1
703 149620 900-101199R
Face Lower SD/SU Guide
Type N2 (76mm)
1
704 110949 149-000010R
2.6x8 Flat Head, Phillips, Self
T
ightening, Binding 3M Screw (Black)
2
705 149640 200-101162R SD SU Plate 1
706 149639 200-101163R SD SU Bracket 1
707 149618 902-100503R Bezel 2 SD/SU Type N 1
708 150124 149-000006R
2.6x5 Flat Head, Phillips, Self
T
ightening, Binding 3M Screw (Black)
2
709 055413 149-000007R
2.6x6 Flat Head, Phillips, Self
T
ightening, Binding 3M Screw (Black)
3
