JCM VEGA Series User Manual

P/N 960-100189RA_Rev. A {EDP #148850} © 2009, Japan CashMachine Co., Limited
7-17
Exploded Views and Parts Lists VEGA™ Series BankNote Validator Section 7
VEGA SD/SU/SDB/SUB Unit Bezel Type D Parts List
Table 7-7 VEGA SD/SU/SDB/SUB Unit Bezel Type D Parts List
Ref N
o
.
EDP Number
JAC N
o
.
Description Qty. Remark
601 148623 902-100505R Bezel SD/SU Type D 1
Type D1 (67mm)
Type D2 (71mm)
Type D3 (68mm)
602
149622 900-101191R
Face Upper SD/SU Guide 
Type D1 (67mm)
1
149624 900-101192R
Face Upper SD/SU Guide 
Type D2 (71mm)
1
149626 900-101193R
Face Upper SD/SU Guide
Type D3 (68mm)
1
603
149623 900-101200R
Face Lower SD/SU Guide
Type D1 (67mm)
1
149625 900-101194R
Face Lower SD/SU Guide
Type D2 (71mm)
1
149627 900-101195R
Face Lower SD/SU Guide
Type D3 (68mm)
1
604 110949 149-000010R
2.6x8 Flat Head, Phillips, Self
T
ightening, Binding 3M Screw (Black)
2
605 149640 200-101162R SD SU Plate 1
606 149639 200-101163R SD SU Bracket 1
607 149621 902-100504R Bezel 2 SD/SU Type D 1
608 150124 149-000006R
2.6x5 Flat Head, Phillips, Self
T
ightening, Binding 3M Screw (Black)
2
609 055413 149-000007R
2.6x6 Flat Head, Phillips, Self
T
ightening, Binding 3M Screw (Black)
3
