JCM VEGA Series User Manual

P/N 960-100189RA_Rev. A {EDP #148850} © 2009, Japan CashMachine Co., Limited
7-5
Exploded Views and Parts Lists VEGA™ Series BankNote Validator Section 7
Upper VEGA Transport Unit Parts List
Table 7-2 Upper VEGA Transport Unit Parts List
Ref N
o
.
EDP Number
JAC N
o
.
Description Qty. Remark
101 144565 900-200300R Upper Transport Frame Top 1
102
144566 900-200301R Upper Transport Frame Bottom 1 without Magnetic Sensor
148822 900-101166R Upper Transport Frame Mag 1 with Magnetic Sensor
103 144571 200-200722R Flap 1 1
104 144572 200-200723R Flap 2 1
105 144574 200-200724R Spring Position Setting Plate 3
106 144582 200-200725R Flap Lever (Left) 1
107 144583 200-200726R Flap Lever (Right) 1
108 144585 900-200302R USB Cover 1
109 145238 900-200303R Harness Cover 2
110 144607 900-200304R Pinch Roller 6
111 144608 200-200729R Flap Axis 1
112 144610 200-200730R Pinch Roller Shaft 3
113 144611 200-200731R Set Pin 11 2
114 144556 200-200732R Pinch Roller Coil Spring 6
115 144622 200-200733R Flap Tension Spring 2
116 140505 300-200153R CPU Board 1
117 140511 300-200154R Sensor Board 1
118 144445 400-100633R Upper Relay Harness Connector R 1
119 144447 400-100634R Signal Power Harness R 2
120 091517 100-100060R Ø2 E-Ring 2
121 104081 186-266000R
2.6x6 Phillips, Self Tightening,
Binding
3M Screw (Black)
6
122 148823 900-101167R TMF Roller 1 with Magnetic Snesor
123 148864 250-100686R TMF Compression Spring
2 with Magnetic Sensor
