JCM VEGA Series User Manual

P/N 960-100189RA_Rev. A {EDP #148850} © 2009, Japan CashMachine Co., Limited
A-4
Appendix A VEGA™ SeriesBankNote Validator Troubleshooting
Red
3
(300)
Red
5
(300)
Cash Box
Seating Problem
Cash Box Sensors detect a Banknotes remaining in p
ath or Cash Box not properly seated.
[Solution] Check that the following parts are properly assembled and/or harness connected,
a
nd clean all of the Sensors.
Cash Box Sensor: SUB Sensor Board LED3 & PS3 & CN1, SUB Board CN6 & CN8, CPU Board
CN7.
If the error is not resolved, change the above related part.
Red
3
(300)
Purple
3
(300)
Pusher
M
echanism
Position Problem
Pusher Mechanism Home Sensor detects that the P
usher Mechanism is not presently seated
at the home end position.
[Solution] Check that the following parts are properly assembled and/or harness connected,
a
nd clean all of the Sensors.
Pusher Mechanism Home Position Sensor: SUB Board LED7
& PT2 & CN8, CPU Board CN8.
If the error is not resolved, change the above related part.
Red
3
(300)
Orange
3
(300)
Stacker Full
When the Pusher Mechanism move
ment proceeds toward stacking, the stacker-full Sensor
determined that the time taken is longer than specified value for the function.
[Solution] Check that the following parts are properly assembled and/or harness connected,
a
nd clean all of the Sensors.
Pusher Mechanism Assembly and inspect movement path.
If the error is not resolved, change the above related part.
Red
3
(300)
Cyan
3
(@100ms)
Pause
*
Intake Sensor detects Banknote at a position where it can not be returned while in the
transportation process.
[Solution] Check that the following parts are properly assembled and/or harness connected,
a
nd clean all of the Sensors.
Intake Sensor: SUB Board LED2 & LED3 & LED4 & L
ED5, CPU Board L57PT & R57PT & L72PT
& R72PT.
If the error is not resolved, change the above related part.
*. Flash error pause time between blinks is a 100msec duration.
Table A-3 Reject Codes
on-line off-line
Error Causes and Solutions
Color
Flashes
(msec)
Color
Flashes
(msec)
Yellow
3
(120)
White
3
(120)
Transport Slip
Detected abnormal Banknotes transportation w
hile transport processing (Transport
Slippage). Sensor does not detect a Banknote even though the number of Banknotes
transported is more than accepted value.
[Solution] Check that the following parts are properly assembled and/or harness connected,
a
nd clean all of the Sensors.
Feed Motor: SUB Board CN2 & CN3, CPU Board CN4. 
Escrow Sensor: CPU Board LED1 & P-SENS1. 
Store Flap Sensor CPU Board
F-SENS1. 
Validation Sensor: Sensor Board (Upper) & Sensor Board (Lower) LED1 & LED3 & PT1, LED2
& LED4 & PT2, LED5 & PT3.
If the error is not resolved, change the above related part or parts.
Yellow
3
(120)
Red
Transport
T
ime-out
Detected an abnormal Banknotes transportation
error when transporting or rejecting
Banknotes (e.g., Transportation Lock-up or operation too slow). Sensors do not detect
movement even though Banknote transportation time is longer than the accepted value.
[Solution] Check that the following parts are properly assembled and/or harness connected,
a
nd clean all of the Sensors.
Feed Motor: SUB Board CN2 & CN3, CPU Board CN4. 
Escrow Sensor: CPU Board LED1 & P-SENS1. 
Store Flap Sensor CPU Board
F-SENS1. 
Validation Sensor: Sensor Board (Upper) & Sensor Board (Low
er) LED1 & LED3 & PT1, LED2
& LED4 & PT2, LED5 & PT3.
If the error is not resolved, change the above related part or parts.
Yellow
Red
3
(120)
Table A-2 Error Codes (Continued)
on-line off-line
Error Causes and Solutions
Color
Flashes
(msec)
Color
Flashes
(msec)
