P/N 960-100189RA_Rev. A {EDP #148850} © 2009, Japan CashMachine Co., Limited
Exploded Views and Parts Lists VEGAâ„¢ Series BankNote Validator Section 7
VEGA Cash Box Unit Parts List
Table 7-5 VEGA Cash Box Unit Parts List
Ref N
o
. EDP N
o
. JAC N
o
.
Description Qty. Remark
401 144587 300-200157R Ceiling Board 1
402 144586 900-200323R Parallel Crank 1 1
403 144588 900-200324R Parallel Crank 2 2
404 144592 900-200355R Pusher Plate 1
405 144595 900-200326R Pusher Prism 2
406 144597 200-200751R Cash Box Link Frame (Left) 1
407 144599 200-200752R Cash Box Link Frame (Right) 1
408 144601 900-200327R Cash Box Turn Guide 1
409 144603 900-200328R Cash Box Turn Course 1
410 144604 900-200329R Tightening Plate 2
411
144605 900-200330R Cash Box (Standard) 1
149629 808-000003R Cash Box 1000 (Large) 1
412 107111 149-000008R
3x10 Phillips, Self Tightening, Binding
3M Screw
4 For Large Cash Box
413 144618 200-200754R Dress Plate 1
414
144619 900-200331R Safe Cover (Standard) 1
149630 900-101179R Safe Cover 1000 (Large) 1
415 144584 200-200755R Bearing 6
416 144652 900-200332R Cash Box Drive Stand Gear 1
417 144657 900-200333R Cash Box Drive Idler Gear 1 1
418 144659 900-200334R Cash Box Drive Idler Gear 2 1
419 144662 900-200335R Box Drive Gear 1
420 144664 900-200336R B Pulley Stand Gear 1
421 144667 900-200337R B Pulley Idler Gear 1 1
422 144671 900-200338R B Pulley Reduction Gear 1
423 144590 900-200339R B Pulley Idler Gear 2 1
424 144591 900-200340R Clutch Gear 1
425
144593 200-200756R Pinion Pantograph 2
426 144594 200-200757R Pinion Drive Gear 1
427 144674 900-200341R Rack Pantograph 1
428 144623 100-381611R Drive Washer 1
429 144624 900-200342R Slide Cover 1
430 144602 900-200343R Drive Pulley 25 4
431 144557 900-200344R Limiter Coil Spring 1
432
144560 250-100687R Conical Spring (Standard Box) 1
149631 250-100688R Conical Spring 1000 (Large Box) 1
433 144561 200-200758R Crank K Spring 1
434 144613 200-200759R Crank Shaft 1
435 144614 200-200760R Box Drive Shaft 1
436 144615 200-200761R Crank Drive Shaft 1
437 144616 200-200762R Pinion Drive Shaft 1
438 144617 200-200763R Cash Box Cover Hinge Axis 1
To Next Page
