P/N 960-100189RA_Rev. A {EDP #148850} © 2009, Japan CashMachine Co., Limited
Exploded Views and Parts Lists VEGA™ Series BankNote Validator Section 7
Lower VEGA Transport Unit Parts List
Table 7-3 Lower VEGA Transport Unit Parts List
Ref N
o
. EDP N
o
. JAC N
o
.
Description Qty. Remark
201
144567 900-200305R Carrier Base 1 without Magnetic Sensor
148821 900-101168R Carrier Base MAG 1 with Magnetic Sensor
202 144568 200-200734R Base Frame 1
203 144573 900-200306R Belt Cover 1
204 144576 200-200735R Gear Box 2
205 144577 200-200736R Tightening Bracket 1
206 144578 200-200737R Snug Fit Latch Plate 1
207 144579 900-200307R Light Prism 1
208 144580 200-200738R Set/Release Latch 2
209 144596 900-200308R Course Path Turning Drive Pulley 2
210 144598 900-200309R Idle Pulley 2
211 144600 900-200310R Support Pulley 6
212 144675 900-200311R Tensioning Pulley 2
213 144625 200-200740R Motor Pinion 2
214 144627 900-200312R B Idle Gear 1 2
215 144631 900-200313R B Idle Gear 2 2
216 144633 900-200314R B Idle Gear 3 2
217 144636 900-200315R Idle Gear 3 2
218 144639 900-200316R U Stand Gear 2
219 144647 900-200317R Idle Gear 4 1
220 144650 900-200318R Flange Gear 2
221 144562 200-200741R Thermal Radiator Plate 2
222 144584 200-200742R Bearing 2
223 144609 200-200743R Course Path Turning Drive Axis 1
224 144612 200-200788R Set Pin 8 2
225 144559 200-200745R Latch Coil Spring 2
2
226 145452 200-200746R Feed Motor 1
227 145455 200-200747R Stacker Motor 1
228 144809 900-200319R Transport Belt 2
229
140509 300-200155R Sub Circuit Board (12V) 1
148644 300-100635R Sub Circuit Board (24V) 1
230 140513 300-200156R Sub Sensor Board 1
231 144446 400-100635R Relay Harness Connector R 1
232 144444 400-100636R Position Sensor Harness R 1
233 144443 400-100637R Stacker Motor Harness R 1
234 144442 400-100638R Feed Motor Harness R 1
235 144844 200-200748
Ø4x12 Parallel Pin Sustainer (B
T
ype/Hard)
8
236 095878 200-200749R Ø3x15 Parallel Pin Sustainer (Hard) 3
237 113898 200-200750R Ø3x18 Parallel Pin Sustainer (Hard) 4
238 144840 171-268000R
2.6x8 Phillips, Self Tightening,
Bi
nding 3M Screw (Black)
13
To Next Page
