System SourceMeter® Instrument Reference Manual Section 7: TSP co
2600BS-901-01 Rev. C / August 2016 7-23
Details
Assigning a value to this attribute enables or disables the storage of timestamps. Reading this
attribute returns the state of timestamp collection.
For dedicated reading buffers, all buffer attributes are saved to nonvolatile memory only when the
reading buffer is saved to nonvolatile memory.
When on, timestamp values are stored with readings in the buffer. This requires four extra bytes of
storage for each reading. Turning on additional collection items, such as timestamps (this attribute)
and source values, decreases the capacity of a dedicated reading buffer (for example,
smua.nvbuffer1), but does not change the capacity of a user-defined dynamically allocated buffer.
This value, off (0) or on (1), can only be changed when the buffer is empty. Empty the buffer using the
bufferVar.clear() function.
Example
smua.nvbuffer1.collecttimestamps = 1
Include timestamps with readings for
dedicated reading buffer 1 (source-measure
Also see
bufferVar.clear() (on page 7-20)
Reading buffers (on page 3-6)
smuX.measure.overlappedY() (on page 7-225)
smuX.measure.Y() (on page 7-229)
smuX.nvbufferY (on page 7-231)
smuX.trigger.measure.Y() (on page 7-264)
bufferVar.fillcount
This attribute sets the reading buffer fill count.
Type TSP-Link accessible Affected by Where saved Default value
Usage
fillCount = bufferVar.fillcount
bufferVar.fillcount = fillCount
The reading buffer fill count
The reading buffer; can be a dynamically allocated buffer (user-defined), or a
dedicated reading buffer (such as smua.nvbuffer1)
