OPERATION
OPERATION
CHECK BRAKE PEDAL TRAVEL
WARNING
If the brake pedal stroke is not 69 to 79 mm (2.7 to 3.1 in) (below 69 mm or over 79 mm), the brake and steering force is too strong
or insufficient. If the stroke is 80 mm (3.2 in) or longer, adjust it.
1.
Depress the brake pedal all the way until it stops.
2.
The distance of travel at the center of the pedal should be 69
to 79 mm (2.7 to 3.1 in).
3.
When this value exceeds 80 mm (3.2 in), or the brake fails to
work, please contact your Komatsu distributor for adjustment.
CHECK THAT LAMPS LIGHT UP
1.
Turn starting switch key to the ON position.
2.
Turn the front lamp switch to the l (ON) position and check that
the front lamp light up.
3. Turn the rear lamp switch to the l (ON) position and check that
the rear lamps on the left and right fenders light up.
If the lamps do not light, check for a broken bulb or disconected
wire, contact your Komatsu distributor for repairs.
3 - 86
