OPERATION
EXPLANATION OF COMPONENTS
DOOR OPEN LOCK
Use this when your want to keep the door held open.
1.
Push the door against door catch (1). The door will be held by
the door catch.
2.
To release the door, move lever (2) inside the cab forward. This
will release the catch.
NOTICE
When keeping the door open, fix it securely to the catch.
Always close the door when traveling or carrying out operations.
Leaving the door open will cause the door to break.
Keep the door locked open securely. The door may swing closed
because of the vibration.
SASH GLASS INTERMEDIATE LOCK
When working with the cab sash glass open, use this lock to
prevent the glass from chattering.
When the lever is in the FREE position, the glass can be opened
or closed.
When the lever is in the LOCK position, the glass is held in
position.
NOTICE
Always close the window when traveling or carrying out operations.
Leaving the window open will cause the window to break.
3 - 51
