Komatsu D85PX-15 User Manual

.
MAINTENANCE
WEAR PARTS
WEAR PARTS
Replace wear parts such as the filter element or cutting edge at the time of periodic maintenance or before they
reach the wear limit. The wear parts should be replaced correctly in order to ensure more economic use of the
machine. When replacing parts, always use Komatsu genuine parts.
As a result of our continuous efforts to improve product quality, the part number may change, so inform your
Komatsu distributor of the machine serial number and check for the latest part number when ordering parts.
WEAR PARTS LIST
The parts in parentheses are to be replaced at the same time.
Item Part No. Part Name
Weight
(kg(lb))
Q'ty
Replacement
frequency
Engine oil filter 600-211-1340 Cartridge - 1
Every 500
hours service
Transmission filter
154-49-71990
(07000-12130)
Element
(O-ring)
-
-
1
(1)
Pre-fuel filter 600-319-3440
Cartridge
(with cap)
-1
Corrosion resistor 600-411-1151 Cartridge - 1
Every 1000
hours service
Fuel filter 600-319-3550
Cartridge
(with cap)
-1
Hydraulic tank breather element 20Y-60-21410 Element - 1
Hydraulic oil filter
207-60-71181
(07000-15195)
Element
(O-ring)
-
-
1
(1)
Every 2000
hours service
Air cleaner 600-185-5100 Element assembly - 1 -
Blade
D85
EX
154-70-11314
154-71-43190
(154-71-41270)
(01643-21845)
(154-70-22270)
150-70-21346
150-70-21356
(154-71-41270)
(01643-21845)
(154-70-22270)
Cutting edge
Cutting edge
(Bolt)
(Washer)
(Nut)
End bit (right)
End bit (left)
(Bolt)
(Washer)
(Nut)
52.9 (117)
41.5 (92)
-
-
-
26.2 (58)
26.2 (58)
-
-
-
1
2
(20)
(20)
(20)
1
1
(12)
(12)
(12)
-
D85
PX
154-70-11314
(154-71-41270)
(01643-21845)
(154-70-22270)
150-70-21346
150-70-21356
(154-71-41270)
(01643-21845)
(154-70-22270)
Cutting edge
(Bolt)
(Washer)
(Nut)
End bit (right)
End bit (left)
(Bolt)
(Washer)
(Nut)
52.9 (117)
-
-
-
26.2 (58)
26.2 (58)
-
-
-
3
(24)
(24)
(24)
1
1
(12)
(12)
(12)
-
Ripper
(Fixed multi-shank ripper)
(Variable multi-shank ripper)
D85
EX
154-78-31330
175-78-31230
(09244-02508)
Protector
Point
(Pin)
12.9 (28.44)
15 (33.08)
-
3
3
(9)
-
NOTICE
When handling parts that weigh more than 25 kg (55 lb), remember that they are heavy objects, and take the necessary care.
4 - 9
