OPERATION
EXPLANATION OF COMPONENTS
B: Caution monitor group (See "CAUTION MONITOR GROUP (PAGE 3-9)")
CAUTION
If the caution lamp for any of these items flashes, check and repair the appropriate item as soon as possible.
These are items which need to be observed when the engine is running. If any problem occurs, the item needing
immediate repair is displayed. If there is any problem, the problem location on the caution lamp will flash.
C: Emergency caution items (for details, see "EMERGENCY CAUTION ITEMS (PAGE 3-11)")
CAUTION
If the caution lamp for any of these items flashes, stop the engine immediately or run it at low idling, and take the following action.
This displays the abnormal items that action must be taken on immediately the engine is running.
If there is any abnormality, the monitor showing the location of the abnormality will flash and the alarm buzzer will
sound.
D: Meter group (for details, see "METER GROUP (PAGE 3-13)")
This consists of the preheating pilot lamp, power train oil temperature gauge, engine water temperature gauge,
hydraulic oil temperature gauge. fuel gauge, dual/single selector display lamp, display panel A (speed range display,
engine speed) and display panel B (multi-information).
E: Switches (for details, see "SWITCHES (PAGE 3-34)".)
These consist of the starting switch, buzzer cancel switch, front lamp switch, rear lamp switch, auto shift down
switch, Preset mode switch, information switch, and Fan rotation selector switch.
F: Lamps (for details, see "LAMPS (PAGE 3-23)".)
These consist of the warning lamp and filter, oil change interval lamp and Fan operation confirmation lamp.
3 - 6
