OPERATION
TRANSPORTATION
TRANSPORTATION
When transporting the machine, observe all related laws and
regulations, and be careful to assure safety.
TRANSPORTATION PROCEDURE
As a rule, transport the machine on a trailer.
Select a trailer according to the mass and dimensions of the machine shown in "SPECIFICATIONS (PAGE 5-2)".
Note that the mass and dimensions for transportation shown in SPECIFICATIONS depend on the types of shoe,
blade, etc.
REMOVAL OF CAB
(Machine equipped with cab) (If equipped)
If it is necessary to remove the cab for transportation, disconnect
the washer hoses, cab wiring, and washer motor wiring before
removing the cab.
1.
Pull the grommet portion in towards the cab from the hole in the
machine cover, then remove.
2. Disconnect 4 washer hoses and the wiring (single wires x 2,
4-pin plug x 1) from the socket.
After removing, cover the washer hoses with a vinyl bag to
prevent any dirt or dust from entering.
Before removing the cab, measure the clearance between
the cab and each lever (joystick and blade control lever,
etc.). Note the measurements to use as a standard when
installing the cab again.
3 - 130
