Printing Operation

bizhub PRO 1050P 5-7

5.3 To Stop Printing

Follow the procedure below to stop printing.

Note

This procedure is effective only for the job in progress. To stop the jobs

on standby, operate on the Job List Screen. For details, refer to “Job Op-

eration on Job List Screen” on page 5-10.

1 Press [Stop] while the current job is in progress.

The current machine operation of the selected job will be suspended,

and the popup menu will be displayed.

2 Touch the desired key on the popup menu.
