Adjustment

9-4 bizhub PRO 1050P

9.2 01 Magnification Adjustment

9.2.1 01 Printer Drum Clock Adjustment <SIDE1>

In the printer control, perform this adjustment to control the magnification for

Side 1 to the direction of paper feed.

Note

This adjustment is a baseline for both sides adjustment enabled in Tray

Setting and Register Type/Weight.
