9
Adjustment
9-40 bizhub PRO 1050P
9.11.4 04 Double Parallel Position Adjustment
Perform this adjustment for the folding positions in Double Parallel folding
mode processed by the FD-501 Folding Unit.
2
Reminder
When adjusting both Single Fold and Double Fold, be sure to start with
the Single Fold adjustment.
The baseline of Single Fold is calculated from the edge of the sheet, while
that of Double Fold is calculated from the position of the first fold line,
therefore a distance (b) in step 5 will be altered by changing the position
of either Single Fold or Double Fold.
To Next Page
