Machine Specifications

18-4 bizhub PRO 1050P

18.1.2 Adobe Post Script3 Expansion kit

Power AC 230V / 15A; 50Hz (This equipment selects the correct volt-

age automatically.)

Power consumption 3.00 KW max. (with option)

Sound power level 80 dB max. (with option)

Weight Approx. 330 kg (main body + ADF)

+ 142 kg w/Paper feeder unit (PF-701)

+ 110 kg w/Large stacker (LS-501/LS-502)

+ 80 kg w/Finisher (FS-503)

+ 120 kg w/Folding unit (FD-501)

Size • 895 (W) x 780 (D) x 1020 (H) mm

(main body excluding control panel)

• 2968 (W) x 780 (D) x 1020 (H) mm

(main body + PF-701 + FD-501 + FS-503)

• 3272 (W) x 780 (D) x 1020 (H) mm

(main body + PF-701 + LS-501 + LS-502)

Effective size* 200 mm or more from the back side; 100 mm or more from

both right and left sides

* Space required for the safe operation
