Adjustment

bizhub PRO 1050P 9-37

9.11.3 03 Letter Fold-out Position Adjustment

Perform this adjustment for the folding positions in Letter Fold-out mode

processed by the FD-501 Folding Unit.

Details

The baseline of Single Fold is calculated from the edge of the sheet, while

that of Double Fold is calculated from the position of the first fold line,

therefore a distance (b) in step 5 will be altered by changing the position

of either Single Fold or Double Fold.
