Preparation for Use

bizhub PRO 1050P 2-9

2.1.5 FD-501 Folding Unit

No. Part name Description

1 Lower cover feed tray holds cover sheets.

2 Lower cover feed tray

guide plates

hold cover sheets to fix the position.

3 Upper cover feed tray holds cover sheets.

4 Upper cover feed tray

guide plates

hold cover sheets to fix the position.

5 Upper cover opens to allow removal of mishandled paper.

6 Folding unit door opens to allow removal of mishandled paper or waste pa-

per.

13 4 5

FD-503

FD-501
