Machine Specifications
18
bizhub PRO 1050P 18-7
18.2.4 FD-501 Folding Unit
Specifications
Functions Punch, Folding, Post inserting (PI), Straight delivery, Output to
secondary tray
Number of punch holes 2 or 4
Hole diameter 6.5 mm
± 0.5 mm (2 holes) / 8.0 mm ± 0.5 mm (4 holes)
Hole pitch 80 mm
± 0.5 mm (2 holes) / 80 mm ± 0.5 mm (4 holes)
Types of paper • 50 to 209 g/m
2
paper (Punch)
• 50 to 130 g/m
2
paper (Folding, Letter Fold-in, Letter Fold-
out, Z-Fold)
• 50 to 91 g/m
2
paper (Double Parallel, Gate)
• 50 to 300 g/m
2
paper when output to secondary (sub) tray,
or conforms to the specifications of selected output device
(Straight delivery)
Output trays Output trays available for the sheets finished through Folding
unit:
• Primary (main) tray / Secondary (sub) tray of FS-503 Finish-
er:
• Secondary (sub) tray on the left side of FD-501 Folding unit:
200 sheets max.
Straight delivery or Punch:
• Any tray mentioned above is available for Straight delivery
or Punch.
• Any tray mentioned above is available for Folding or Z-Fold.
• Secondary (sub) tray on the left side of FD-501 is available
only for Letter Fold-in, Letter Fold-out, Double Parallel, or
Gate.
Cover paper type PPC, HQ, coated, tracing (50 to 300 g/m
2
paper)
Paper sizes • 4-hole punch:
A3, B4, A4, B5, 12"x18", 11"x17", 8.5"x11", 8K, 16K
• 2-hole punch:
A3, B4, A4, A4R, B5, B5R, A5, A5R, F4, 12"x18", 11"x17",
8.5"x14", 8.5"x11", 8.5"x11"R, 5.5"x8.5", 8K, 16K
• Folding:
A3, B4, A4R, 12"x18", 11"x17", 8.5"x14", 8.5"x11"R, 8K
• Post inserting:
A3, B4, A4, A4R, B5, B5R, A5, F4, 12"x18", 11"x17",
8.5"x14", 8.5"x11", 8.5"x11"R, 5.5"x8.5", 8K, 16K, 16KR,
tabbed standard sizes, wide sizes (max. 324mm x 460mm)
• Straight delivery:
conforms to the specifications of selected output device
Stack capacity using PI 500 sheets max. (80 g/m
2
paper) for each tray
Dimensions 400 (W) x 656 (D) x 1190 (H) mm
Weight Approx. 120 kg
Power source Internal battery
